Knuckleboom hand signals

Mahk_Adams

Active Member
Anyone know if there are standard hand signals for knuckleboom cranes for boom up/down/extend/retract for the main boom vs. the jib?

Thanks

If it was me offering guidance to anyone operating a knuckle boom in your field. I would first agree on what the different boom components or sections are called. Swing, Main boom, Outer boom, Outer boon extensions, Fly jib, Fly jib extensions. Something along those lines. I would suggest using a good head set so both the crane operator and the person giving the commands clearly hear each other.

Here is the hand signals used in the NCCCO training manual page 54


Attachments

classictruckman

Well-Known Member
Those signals are standard crane signals, I agree discuss it before hand.

In the past i've tapped my elbow to indicate I was signaling for the jib. According to the standard crane signals tapping your elbow is for the aux. winch, since most kbooms don't even have 1 winch I think it translates well.


classictruckman

Well-Known Member
Years ago I probably would have done the same, until I was signaling to an inexperienced kboom operator, and had to stand there for a second thinking about how I was going to get him to do what I wanted.


allmark

Well-Known Member
I have used the standard signals for boom up and down and extend or retract. The only difference for the fly jib being raising the signal hand over the head for the jib and at normal height for the 2nd boom.
